Robotis BIOLOID GP - Assembly Guide: Part 4 (Steps 7-8); Hand, Arm, and Gyroscope Assembly

18
STEP
7
STEP
8
Robot
Frontsid
Robot
Backside
Fasten front-sided 2 bolts only
Attach hand to arm, then attach to body frame.
( refer to tip 1, hand and horn orientation)
Attach gyroscope board and FR04-E191 bracket to FR04-E131 back frame.
