Robustel R2000 Installation And Configuration Quick Guide

-3-
Name
Color
Status
Description
USR-NET
Green
On, solid
Network is joined successfully and
worked in an optimum one
On, blinking
Network is joined successfully but
worked in a lower-level than
standard
Off
Network is not joined or joining
USR-
OpenVPN
Green
On, solid
OpenVPN connection is established
Off
OpenVPN connection is not
established
USR-IPsec
Green
On, solid
IPsec connection is established
Off
IPsec connection is not established
USR-WiFi
Green
On, solid
WiFi is enabled and working
properly
Off
WiFi is disabled or not working
properly
Green
On, solid
High Signal strength (21-31) is
available
On, solid
Medium Signal strength (11-20) is
available
On, solid
Low Signal strength (1-10) is
available
Off
No signal
On, blinking
When the network is disconnected,
those three signal LEDs are
designed as a binary combination
code to indicate a series of error
report.
Blinking: 1 Off: 0
001 AT command failed
010 no SIM card detected
011 need to enter the PIN code
100 need to enter the PUK code
101 registration failed
110 module error
111 not support the module
4. Reset Button
Function
Operation
Reboot
Press and hold the RST button for 2 to 7 seconds under
the operating status.
Restore to factory
default settings
Wait for 5 seconds after powering up the router, press
and hold the RST button until all six LEDs start blinking
one by one, and release the button to return the router
to factory defaults.
5. Ethernet Port
There are two Ethernet ports on R2000 Router, including ETH0 and ETH1. The
ETH0 on the router can be configured as either a WAN port or LAN port, also
can be assigned as a PoE port, while ETH1 can only be configured as a LAN
port. Each has two LED indicators. The yellow one is a link indicator but the
green one doesn’t mean anything. For details about status, see the table
below.
Indicator
State
Description
Link indicator
On, solid
Connection is established
On, blinking
Data is being transferred
Off
Connection is not established

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
