Robustel R2000 Installation And Configuration Quick Guide

-8-
Router Configuration
1.
Log in the Router
To log in to the management page and view the configuration status of your
router, please follow the steps below.
1. On your PC, open a web browser such as Internet Explorer, Google or
Firefox etc.
2. From your web browser, type the IP address of the router into the
address bar and press enter. The default IP address of the router is
192.168.0.1, though the actual address may vary.
3. In the login page, enter the username and password, choose language
and then click LOGIN. The default username and password are
“admin”.
Note: If enter the wrong username or password over six times, the
login web will be locked for 5 minutes.
4. After logging in, the home page of the R2000 Router’s web interface is
displayed, for example.
Note: To configure parameters should follow this order “modify
parameter 1 > Submit > modify parameter 2 > Submit > Save & Apply”.
2. Configure the Cellular Connection
Click Interface > Link Manager > Link Manager > General Settings,
choose “WWAN1” as the primary link and “WWAN2” as the backup
link, and set “Cold Backup” as the backup mode, then click “Submit”.
Note: Link Settings allows you to configure the parameters of link
connection, including WWAN1/WWAN2, WAN and WLAN. It is
recommended to enable Ping detection to keep the router always
online. The Ping detection increases the reliability and also costs the
data traffic.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
