Robustel R2000 Installation And Configuration Quick Guide

-5-
4. Mount the Router
The router can be placed on a desktop or mounted to a wall or a 35 mm DIN
rail.
Two methods for mounting the router
 Wall mounting (measured in mm)
Use 4 pcs of M2.5*4 flat head Phillips screws to fix the wall mounting
kit to the router , and then use 2 pcs of M3 drywall screws to mount
the router associated with the wall mounting kit on the wall.
Note: Recommended torque for mounting is 0.5 N.m, and the
maximum allowed is 0.7 N.m.
 DIN rail mounting (measured in mm)
Use 3 pcs of M3*6 flat head Phillips screws to fix theDIN rail to the
router, and then hang the DIN rail on the mounting bracket. It is
necessary to choose a standard bracket.
Note: Recommended torque for mounting is 1.0 N.m, and the
maximum allowed is 1.2 N.m.
5. Connect the Router to a Computer
Connect an Ethernet cable to the port marked ETH0 or ETH1 at the bottom
of the router, and connect the other end of the cable to your computer.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
