Roca LAURA 20 - Control Panel

Control Panel
14
1. Pressure gauge
2. Heating+DHW service
3. DHW service
4. Stop
5. Fault Warning and Reset Button
6. Set Central Heating Temperature
7. Set DHW Temperature
8. Operating Temperature
Control Knob
9. Digital LCD Display
10. Set Time
11. Validate Program
12. Mode Selection: Manual/Program
13. Set Day
14. Set Day/Time/Programmer Knob
Air Purge
Circulator
Flow Meter
Control Panel for
Laura 20/20F
1
3
2
4
5
8
10
14
13
12
11
9
7
6
Laura 20/20F wall-hung waterheaters
