Safety Valve and By-Pass
25
Bypass automatic valve
Safety valve
Set at 43.5 psi / 3 bar
Flow to radiators
Bypass connection
Opens at 5.8 psi / 0.4 bar
Inlet from heat
exchanger
Laura 20/20F wall-hung waterheaters
