Roca LAURA 20 - Combustion Chamber

Combustion Chamber
36
Front insulation panel
Material: Ceramic Fibre
Side insulation panels
Material: Ceramic Fibre
Side tabs
Fold them after fitting
side insulation panels
Threaded Rods for Chassis
fixing M5
Compact
combustion chamber
Do not start the boiler until the insulation panels have been properly assembled. For
optimum boiler operation it is essential that these insulation panels be in good condition.
M5 Set Nuts
For fixing the burner baffle plate
Laura 20/20F wall-hung waterheaters
