Roca LAURA 20 - Burner

Burner
35
Baffle plate
Gas valve pressure
test point bracket
13 becks
Material: Stainless Steel
Ignition Electrodes
Centered on the middle burner 5 mm higher and
a 4 mm electrode gap
Cable entry bracket plate
Without inter-ignition rods
Burner fixing to the
gas valve
Allen 4 x 15
Ignition Sequence
2 seconds at 27,769 Btu
3 seconds at 47,604 Btu
Flame sensing rod
Average current: 3µA
Safety time period: 5 seconds
Laura 20/20F wall-hung waterheaters
