Rocal RCr - Technical Characteristics

Pag. 12
I: TECHNICAL CHARACTERISTICS
Model
Parameter
RCr 50 V
RCr 65
RCr 70
RCr 70 A
RCr 80
RCr 100
RCr 70
CONICO
Maximum smokestack intake
11-13 Pa
Fuel consumption
1,9 Kg/h
1,9 Kg/h
2,2 Kg/h
2,2 Kg/h
2,4 Kg/h
3,2 Kg/h
1,9 Kg/h
Mass smoke intake
4,8 g/s
6,7 g/s
6 g/s
6 g/s
11,5 g/s
8 g/s
8 g/s
Nominal efficiency
80%
77%
80%
80%
81%
80%
77%
Output
7 Kw
6,5 Kw
7,5 Kw
7,5 Kw
9,1 Kw
10,5 Kw
6,5 Kw
Maximum output
11 Kw
12 Kw
15 Kw
15 Kw
16 Kw
18 Kw
12 Kw
CO concentration at an average of
13% O2
0,10%
0,26%
0,12%
0,12%
0,13%
0,26%
0,26%
Particle concentration
15mg/Nm
3
(*)
17mg/Nm
3
(*)
16mg/Nm
3
16mg/Nm
3
19mg/Nm
3
20mg/Nm
3
17mg/Nm
3
(*)
Fuel load (test)
1,5 Kg
1,4 Kg
1,8 Kg
1,8 Kg
2,4 Kg
2,3 Kg
1,9 Kg
Period time to test
47 min.
45 min.
49 min.
49 min.
45 min.
43 min.
45 min.
Average smokestack intak (test)
12 Pa
12 Pa
12,5 Pa
12,5 Pa
13,3 Pa
12,5 Pa
12 Pa
Net Weight
93 Kg
79,5 Kg
95 Kg
99 Kg
119 Kg
148 Kg
88 Kg
Maximum fuel load
3 Kg
3 Kg
4 Kg
4 Kg
4 Kg
5 Kg
4 Kg
High recharge
200 mm
175 mm
175 mm
175 mm
175 mm
175 mm
175 mm
Length woodlogs
300 mm
400 mm
450 mm
450 mm
500 mm
600 mm
400 mm
Minimum height of pipe
4000 mm
Ø Flue duct
150 mm
150 mm
150 mm
150 mm
180 mm
200 mm
150 mm
Ø Air outlet ducs
120 mm
Inner fireplace room safety
distances (back)
50 mm
Inner fireplace safety distances
(sides)
50 mm
Outer fireplace safety distances
(back)
200 mm
150 mm
200 mm
200 mm
200 mm
200 mm
200 mm
Outer fireplace safety distances
(sides)
200 mm
250 mm
200 mm
200 mm
200 mm
150 mm
200 mm
Outer fireplace safety distances
(frontal)
1000 mm
Fireplace room ventilation
(entry - exit)
450 cm2
Ø Electric cable exit
8 mm
Fun airflow (unit)
135 m3/h
Fun output (unit)
20 w
Primary register
0% open
0% open
0% open
0% open
0% open
25% open
0% open
Secondary register
40%
open
20%
open
50%
open
50%
open
50%
open
100%
open
50%
open
Minimum safety distance to the air
outlets
250 mm
Temperature of fumes
292º C
261º C
281º C
281º C
189º C
273º C
290º C
Fire type
ON AND OFF
Pipe
NOT SHARE
Fuel
NATURAL WOOD
Logs humidity
12-20 % - 2 UNDER COVER
Cetification year
2011
2013
2013
2013
Nº Certificate
CEE/039/
13
11-2312-
895-S
CEE/039/
13
CEE/039/
13
16/12165-
714
CEE/040/
13
CEE/040/
13
(*) Values obtained from Rocal laboratory test
