Rocal RCr - Detailed Components; Diagrams and Measures; Connection Pictures; Assembly Pictures

Pag. 11
ENGLISH
WARNING:
IT’S VERY IMPORTANT THAT BEFORE BEGINNING THE INSTALLATION AND STARTUP OF
THE APPLIANCE READ AND FOLLOW THESE INSTRUCTIONS.
A: DETAILED COMPONENTS
1.
Pot with aerosol painting for final finish
2.
Tool to manage the air slider (primary and secondary) and door
3.
Anti-scratching cloth for cleaning the plate
4.
Exothermic glove
5.
Envelope containing user’s guide: characteristics, assembly, operating and guarantee
6.
Bag with screws and washers to connect air outlet adapters
7.
Air outlet adapters
B: DIAGRAMS AND MEASURES
Model
Parameter
RCr 50 V
RCr 65
RCr 70
RCr 70 A
RCr 80
RCr 100
RCr 70
CONICO
A – Total width
550 mm
670 mm
725 mm
725 mm
819 mm
1019 mm
692 mm
B – Total high
702 mm
500 mm
512 mm
565 mm
587 mm
612 mm
511 mm
C – Width
509 mm
629 mm
684 mm
684 mm
778 mm
978 mm
488 mm
D – High
680 mm
478 mm
490 mm
543 mm
565 mm
590 mm
489 mm
E- Depth
425 mm
425 mm
460 mm
460 mm
476 mm
476 mm
471 mm
F – Total Depth
435 mm
435 mm
470 mm
470 mm
486 mm
486 mm
481 mm
G- Distance to out smoke
center
145 mm
145 mm
165 mm
165 mm
170 mm
170 mm
193 mm
H – Ø Out smoke
150 mm
150 mm
150 mm
150 mm
175-180 mm
200 mm
150 mm
C: CONNECTION PICTURES
1.
Assembly pictures WITHOUT AIR AOUTLET CONNECTION
2.
Assembly pictures WITH AIR OUTLET CONNECTION
D: ASSEMBLY PICTURES
E: DISMANTLING FORCED AIR VENTILATION SYSTEM PICTURES
F: SCHEMES FOR CHANGE DIRECTION OF OPENING THE DOOR
G: SPARE PARTS PICTURE
1.
Vitroceramic glass
1- A
Vitroceramic decorared glass ** Only models GRAFFITI **
2.
Vermiculite deflected panel pieces
3.
Vermiculite deflected panel pieces metallic support
4.
Vermiculite back pieces
5.
Vermiculite side pieces
6.
Side metallic fire protection pieces ** Only for models 80 y 100 **
7.
Fire grate
8.
Fun of 135 m3/h
9.
Ash pan
10.
Frontal metallic fire protection piece
H: OPTIONAL COMPLEMENTS
1 - 2
Optional foot (according adjustable, adjustable height measures)
3
Adapter to 4 sides frame
4
4 sides frame scheme
5 - 6
4 sides of 8 cm frame scheme
