RF-TVMFM03V2 TV Wall Mount
Step 4 Install the horizontal TV brackets
1 Slide the horizontal brackets (C) through the metal guides on the vertical TV brackets until they are centered.
2 Secure the horizontal TV brackets to the vertical TV brackets using the 8-32 x 9/16" Phillips head screws (V).
Tighten the screws until they are snug, but do not over tighten.
Note: Make sure that the brackets are not covering any jacks or connectors.
You’l l need
V (4)
Phillips screwdriver
Horizontal brackets (C)
RF-TVMFM03V2_13-0190_MAN_V2_ENG - GIF.fm Page 10 Thursday, March 14, 2013 11:27 AM
