13
Need help? Call 800-620-2790
RF-TVMLPT02V2 TV Wall Mount
STEP 7 - Adjusting the level and tilt angle
1 Adjust the swivel tension by hand or by using a 3/16" hex key (not included), then adjust the tilt angle by
gripping the top and bottom of the TV and manually moving the TV to the angle you want. When you are
done adjusting the tilt, retighten the knob, but do not over-tighten.
2 Adjust the level by tightening or loosening the screws on the tops of the vertical brackets.
You’ll n eed
Phillips screwdriver
Level
RF-TVMLPT02V2_13-0194_MAN_V2_EN - GIFs.fm Page 13 Thursday, March 14, 2013 12:01 PM
