9RF-WHP01/WHP02
Docking station back (WHP01)
Docking station back (WHP02)
Item Description
1 Manual connect button
2 Volume control knob
3DC IN jack
4 AUX Input jacks
5AUX Output jacks
Item Description
1 Manual connect button
2DC IN jack
3 AUX Input jacks
1
CONNECT
RL
AUX INPUT
RL
AUX OUTPUT
DC IN
5V
VOL
2
3
4
5
1
3
4
5
2
