Rocktron REPLITONE MP - Specifications

23
Input Impedance
Maximum Input Level
Input Jack
Output Impedance
Maximum Output Level
Output Jacks
MIDI In
MIDI Thru/Out
Power Requirements
Effects Loop
Dimensions
470k
0dBu
1/4" Mono
<150 Ohms
+7dBu
1/4 Left and Right
7-pin Din - Pins 6&7 Carry Phantom Power to run
Rocktron MIDI Mate and MIDI I.T. Footcontrollers.

5-pin Din
9VAC / 3.4A
1/4" stereo jack (TRS) for send and return. Tip is left
channel. Ring is right channel.
19" x 7" x 1 3/4"
13. Specifications
