MicroLogix 1400 Programmable Controllers 21
Publication 1766-IN001D-EN-P - June 2015
Wiring Recommendation
When wiring without spade lugs, keep the finger-safe covers in place. Loosen the terminal
screw and route the wires through the opening in the finger-safe cover. Tighten the terminal
screw, making sure the pressure plate secures the wire.
Be careful when stripping wires. Wire fragments that fall into the controller
could cause damage. Once wiring is complete, be sure the controller is free of
all metal fragments before removing the protective debris strip. Failure to
remove the strip before operating can cause overheating.
