8 MicroLogix 1400 Programmable Controllers
Publication 1766-IN001D-EN-P - June 2015
Controller Input and Output Description
Catalog
Number
Description
Input
Power
User
Power
Embedded
Discrete I/O
Embedded
Analog I/O
Comm.
Ports
1766-L32BWA
100/240V AC
24V DC
12 Fast 24V DC Inputs
8 Normal 24V DC Inputs
12 Relay Outputs
None
1 RS232/RS485
(1)
1 Ethernet/IP
1 RS232
(2)
1766-L32AWA
None
20 120V AC Inputs
12 Relay Outputs
1766-L32BXB 24 V DC
12 Fast 24V DC Inputs
8 Normal 24V DC Inputs
6 Relay Outputs
3 Fast DC Outputs
3 Normal DC Outputs
1766-L32BWAA
100/240V AC
24V DC
12 Fast 24V DC Inputs
8 Normal 24V DC Inputs
12 Relay Outputs
4 Voltage Inputs
2 Voltage
Outputs
1766-L32AWAA
None
20 120V AC Inputs
12 Relay Outputs
1766-L32BXBA 24V DC
12 Fast 24V DC Inputs
8 Normal 24V DC Inputs
6 Relay Outputs
3 Fast DC Outputs
3 Normal DC Outputs
(1)
Isolated RS-232/RS-485 combo port. Same as ML1100 Comm 0
(2)
Non-isolated RS-232. Standard D-sub connector
