FLEX I/O Digital DC Output Modules 23
Publication 1794-IN094D-EN-P - July 2018
Derating Curve for 1794-OB16P
0
15
10
25
20
30
31.2
10 20 30 40 50 55 60
Ambient Temperature
o
C
The area within the curve represents the safe operating range for the module
under various conditions of user supplied 24V DC supply voltages and ambient
temperatures.
= Normal mounting safe operating range, (includes ).
= Other mounting positions (including inverted horizontal) safe operating
3732
28.5
27.5
Normal Mounting – Horizontal
Other Mounting (including Vertical, and Inverted Horizontal
Mounting)
in
V
On-State
Voltage
(V DC)
