Supplemental Drive Information A-3
Category Specification
Environment Altitude: 1000 m (3300 ft) max. without derating
Ambient Operating Temperature
IP20:
NEMA 1:
–10 to 50 degrees C (14 to 122 degrees F)
–10 to 40 degrees C (14 to 104 degrees F)
Cooling Method
Convection:
Fan:
0.2 kW (0.25 HP) drive ratings, Catalog Numbers
22A-V1P5N104, 22A-A1P5N114, 22A-A1P5104
and 22A-B1P5N104
All other drive ratings.
Storage Temperature: –40 to 85 degrees C (–40 to 185 degrees F)
Atmosphere: Important: Drive m
ust not be installed in an
area where the ambient atmosphere contains
volatile or corrosive gas, vapors or dust. If the
drive is not going to be installed for a period of
time, it must be stored in an area where it will not
be exposed to a corrosive atmosphere.
Relative Humidity: 0 to 95% non-condensing
Shock (operating): 15G peak for 11ms duration (±1.0ms)
Vibration (operating): 1G peak, 5 to 2000 Hz
Control Carrier Frequency 2-16 kHz. Drive rating based on 4 kHz.
Frequency Accuracy
Digital Input:
Analog Input:
Within ±0.05% of set output frequency.
Within 0.5% of maximum output frequency.
Speed Regulation - Open Loop
with Slip Compensation:
±2% of base speed across a 40:1 speed range.
Stop Modes: Multiple programmable stop modes including -
Ramp, Coast, DC-Brake, Ramp-to-Hold and
S Curve.
Accel/Decel: Two independently programmable accel and
decel times. Each time may be programmed from
0 - 600 seconds in 0.1 second increments.
Intermittent Overload: 150% Overload capability for up to 1 minute
200% Overload capability for up to 3 seconds
Electronic Motor Overload
Protection
Class 10 protection with speed sensitive
response.
