3-26 Programming and Parameters
Parameter Cross Reference – by Name
Parameter Name No. Group
0-10V Analog Input d020 Display
0-10V Analog Input High A111 Advanced Program
0-10V Analog Input Low A110 Advanced Program
4-20mA Analog Input d021 Display
4-20mA Analog Input
High
A113 Advanced Program
4-20mA Analog Input
Low
A112 Advanced Program
Accel Time 1 P039 Basic Program
Accel Time 2 A067 Advanced Program
Auto Rstrt Delay A093 Advanced Program
Auto Rstrt Tries A092 Advanced Program
Comm Data Rate A103 Advanced Program
Comm Format A107 Advanced Program
Comm Loss Action A105 Advanced Program
Comm Loss Time A106 Advanced Program
Comm Node Addr A104 Advanced Program
Comm Status d015 Display
Commanded Freq d002 Display
Compensation A097 Advanced Program
Contrl In Status d013 Display
Control Source d012 Display
Control SW Ver d016 Display
Current Limit A089 Advanced Program
DB Resistor Sel A082 Advanced Program
DC Brake Level A081 Advanced Program
DC Brake Time A080 Advanced Program
DC Bus Voltage d005 Display
Decel Time 1 P040 Basic Program
Decel Time 2 A068 Advanced Program
Dig In Status d014 Display
Digital Inx Sel A051, A052 Advanced Program
Drive Status d006 Display
Drive Type d017 Display
Elapsed Run Time d018 Display
Fault x Code d007-d009 Display
Fault Clear A100 Advanced Program
Flying Start En A096 Advanced Program
Internal Freq A069 Advanced Program
Jog Accel/Decel A079 Advanced Program
Jog Frequency A078 Advanced Program
Maximum Freq P035 Basic Program
Maximum Voltage A088 Advanced Program
Minimum Freq P034 Basic Program
Motor NP Hertz P032 Basic Program
Motor NP Volts P031 Basic Program
Motor OL Current P033 Basic Program
Motor OL Select A090 Advanced Program
Output Current d003 Display
Output Freq d001 Display
Output Voltage d004 Display
Preset Freq x A070-A073 Advanced Program
Process Display d010 Display
Process Factor A099 Advanced Program
Program Lock A101 Advanced Program
PWM Frequency A091 Advanced Program
Relay Out Level A056 Advanced Program
Relay Out Sel A055 Advanced Program
Reset To Defaults P041 Basic Program
Reverse Disable A095 Advanced Program
S Curve % A083 Advanced Program
Slip Compensation A114 Advanced Program
Speed Reference P038 Basic Program
Start At PowerUp A094 Advanced Program
Start Boost A084 Advanced Program
Start Source P036 Basic Program
Stop Mode P037 Basic Program
SW Current Trip A098 Advanced Program
Testpoint Data d019 Display
Testpoint Sel A102 Advanced Program
Parameter Name No. Group
