Rockwell Automation Publication 7000-IN008D-EN-P - August 2019 19
Chapter 2
Transportation and Handling Procedures
Planning
Verify that you can move the equipment into place. Check that all ceiling, door
heights, and turning distances are adequate. Prepare and verify the level of the
intended drive site.
Leveling
Prepare a level concrete surface for the equipment at the final installation site.
Verify that the siting surface is level to +/- 1 mm per meter (+/-0.036 in. per
36 in.) in all directions.
Once you position the drive, test the level. If necessary, shim the equipment with
sheet metal to level the mounting. If joining shipping splits, level and shim prior
to joining the cabinets to avoid torquing or twisting the cabinets on a non-level
surface.
Rigging Contractor
Rockwell Automation strongly recommends that you contract professional
riggers with suitably-rated lifting equipment to move the drive to its final
installation site.
IMPORTANT Improperly leveled sites can inhibit proper set-up by introducing
misalignments in joining hardware or interfering with latch and interlock
operations.
ATTENTION: Do not lift or move the drive by any means other than the
handling methods listed in this publication. Failure to do so can result in
personal injury or equipment damage.
