Rockwell Automation Allen-Bradley Stratix 2000 Series User Manual

Stratix 2000 Ethernet Unmanaged Switches 5
Rockwell Automation Publication 1783-PC002C-EN-P - May 2014
Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at
http://www.rockwellautomation.com/literature/. To order paper copies of technical documentation, contact your local Allen-Bradley distributor or Rockwell Automation sales representative.
Attribute 1783-US5T, 1783-US8T 1783-US4T1F, 1783-US4T1H, 1783-US5TG, 1783-US6T2F, 1783-US6T2H,
1783-US6TG2CG, 1783-US7T1F, 1783-US7T1H, 1783-US14T2S, and 1783-US16T
Wire size, power connectors
0.82…2.1 mm
2
(18…14 AWG) solid or stranded copper wire rated at 105 °C (221 °F) or greater.
Wire size, chassis ground connection
2.5 mm
2
(14 AWG) min 2.5 mm
2
(14 AWG) min
Screw torque, chassis protective earth ground
terminal (PE)
1.82 N
m (16.10 lbin)
Torque must not exceed 1.82 N
m
1.82 N
m (16.10 lbin)
Torque must not exceed 1.82 N
m
Screw torque, power terminals 0.4 Nm (3.5 lbin)…0.5 Nm (4.4 lbin) 0.4 Nm (3.5 lbin)…0.5 Nm (4.4 lbin)
Power supply Input voltage 24V DC/AC (18…60V DC; 18…30V AC))
Temperature rating 75 °C (167 °F) only for the field installed conductors.
Input voltage 24V DC/AC (18…60V DC; 18…30V AC))
Temperature rating 75 °C (167 °F) only for the field installed conductors.
Catalog Number Nominal Voltage (V DC) Voltage Range DC
(Class 2 Power Source)
Voltage Range AC
(Class 2 Power Source)
Operating Temperature Ratings Temperature Code ATEX String
1783-US5T 24V DC 18…60V DC 18…30V AC 0…60 °C (32…140 °F) 250 mA max, 2 W max T5 Ex nA IIC T5 Gc
1783-US8T 24V DC 18…60V DC 18…30V AC 0…60 °C (32…140 °F) 361 mA max, 4.04 W max T5 Ex nA IIC T5 Gc
1783-US7T1F
1783-US7T1H
24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 442.3 mA, 5.927 W max T4 Ex nA IIC T4 Gc
1783-US6T2F
1783-US6T2H
24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 442.3 mA, 5.927 W max T4 Ex nA IIC T4 Gc
1783-US16T 24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 555.5 mA, 6.72 W max T4 Ex nA IIC T4 Gc
1783-US14T2S 24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 663.2 mA, 7.991 W max T4 Ex nA IIC T4 Gc
1783-US4T1F
1783-US4T1H
24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 230.5 mA, 2.841 W max T4 Ex nA IIC T4 Gc
1783-US5TG 24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 432.1 mA, 5.491 W max T4 Ex nA IIC T4 Gc
1783-US6TG2CG 24V DC 18…60V DC 18…30V AC -40…70 °C (-40…158 °F) 1242.7 mA, 13.643 W max T4 Ex nA IIC T4 Gc
Resource Description
Stratix Ethernet Managed Switches Technical Data, publication
1783-TD001 Provides specification information for the switches.
Industrial Automation Wiring and Grounding Guidelines, publication
1770-4.1
Provides general guidelines for installing a Rockwell Automation

industrial system.
Product Certification website,
http://www.rockwellautomation.com/products/certification Provides declarations of conformity, certificates, and other certification details.
