ControlLogix Power Supplies 17
Publication 1756-IN613A-EN-P - December 2008
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF immunity
IEC 6100-4-6
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
EFT/B immunity
IEC 61000-4-4
±4 kV at 5 kHz on power ports
Surge transient immunity
IEC 61000-4-5
±1 kV line-line (DM) and ±2 kV line-earth (CM) on power ports
Oscillatory surge withstand
IEEE C37.90.1
3 kV
Enclosure type rating None (open style)
Voltage variation
IEC 61000-4-11
30% dips for 1 period at 0° and 80° on AC supply ports
60% dips for 5 and 50 periods on AC supply ports
±10% fluctuations for 15 min on AC supply ports
>95% interruptions for 250 periods on AC supply ports
1756-PA72 Series C, 1756-PA75 Series B - Certifications
(1)
Certifications
(2)
1756-PA72 Series C 1756-PA75 Series B
UL UL Listed Industrial Control Equipment. See UL File E65584
CSA Certified Process Control Equipment. See CSA File LR54689C
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D
Hazardous Locations. See CSA File LR69960C
FM Approved Equipment for use in Class 1 Division 2 Group A,B,C,D Hazardous
Locations
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN61000-6-2; Industrial Immunity
EN61000-6-4; Industrial Emissions
EN61131-2; Programmable Controllers (Clause 8, Zone A,B, C)
European Union 2006/95/EC LVD, complaint with:
EN 61131-2; Programmable Controllers (Clause 11)
C-Tick Australian Radio Communications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
TÜV TÜV Certified for Functional Safety:
up to and including SIL 2 (1756-PA75 only)
(1)
When product is marked.
(2)
See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification
details.
1756-PA72 Series C, 1756-PA75 Series B - Environmental Specifications
Attribute 1756-PA72 Series C 1756-PA75 Series B
