Rockwell Automation ControlLogix 1756-PA72 Series C User Manual

ControlLogix Power Supplies 19
Publication 1756-IN613A-EN-P - December 2008
North American temp
code
T4
IEC temp code T4 N/A
Mounting screw
torque
0.8 N•m (7 lb•in)
(1)
Input may drop to 16V for a maximum of two minutes each hour for motor starting.
(2)
The combination of all output power (1.2V, 3.3V, 5.1V, and 24V) cannot exceed 75 W.
(3)
The hold up time is the time between input voltage removal and DC power failure.
(4)
Use time-delay type overcurrent protection in all ungrounded conductors.
(5)
This fuse is intended to guard against fire hazard due to short circuit conditions.
(6)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
.
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Environmental Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B
Operating
temperature
IEC 60068-2-1 (Test
Ad, Operating Cold)
IEC 60068-2-2 (Test
Bd, Operating Dry
Heat)
IEC 60068-2-14 (Test
Nb, Operating
Thermal Shock)
0…60 °C (32…140 °F)
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Technical Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B

Rockwell Automation ControlLogix 1756-PA72 Series C Specifications

General

Brand	Rockwell Automation
Model	ControlLogix 1756-PA72 Series C
Category	Power Supply
Language	English
