Rockwell Automation STRATIX 8000 1783-MS06T User Manual

Publication 1783-UM002C-EN-P - April 2009 27
Chapter 2
The following table lists some port combinations using switch and expansion
modules.
The following figure displays example combinations of the 1783-MS06T
switch and expansion modules. The same combinations of expansion modules
can be used with a 1783-MS10T switch.
Switch and Expansion Module Port Combinations
Port Type Switch and Expansion Modules Combination
100FE
(copper)
100FX
(fiber optic)
4 one 1783-MS06T switch
8 one 1783-MS10T switch
4 8 one 1783-MS06T switch
one 1783-MX08F expansion module
12 one 1783-MS06T switch
one 1783-MX08T expansion module
8 8 one 1783-MS10T switch
one 1783-MX08F expansion module
16 one 1783-MS10T switch
one 1783-MX08T expansion module
12 8 one 1783-MS06T switch
one 1783-MX08T expansion module
one 1783-MX08F expansion module
20 one 1783-MS06T switch
two 1783-MX08T expansion modules
16 8 one 1783-MS10T switch
one 1783-MX08T expansion module
one 1783-MX08F expansion module
24 one 1783-MS10T switch
two 1783-MX08T expansion modules
