Rockwell Automation STRATIX 8000 1783-MS06T

28 Publication 1783-UM002C-EN-P - April 2009
Chapter 2
1 1783-MS06T switch with 1783-MX08T and 1783-MX08F expansion modules (12 copper and 8 fiber optic ports)
2 1783-MS06T switch with one 1783-MX08F expansion module (4 copper and 8 fiber optic ports)
3 1783-MS06T switch with one 1783-MX08T expansion modules (12 copper ports)
4 1783-MS06T switch with two 1783-MX08T expansion modules (20 copper ports)
2
3
1
1
4
