12
GB
CV Name Description Value
Range
Works
Value
6 Average voltage Determines the locomotive speed in the middle
driving stage
01 – 252 85
7 Version number Internal software version of the decoder (only
reading)
------- -------
8 Manufacturer ID NMRA identification number from the manufac-
turer Zimo.
08 (Reset) 145
17 Long address High-value byte 192 – 231 192
18 Long address Low-value byte 00 – 255 128
28
RailCom
1)
Selecting the RailCom
1)
transmission functions
00 – 3 3
29 Conguration
register
Diverse locomotive settings, only relevant in DCC
operation. Add the values of each of the functions
to determine the value of the CV29
Bsp.: 28 driving stages + permit analogue
operation = 2+4 = 6.
0 – 255 14
155 Shunting key Number of the function key which is used to
decelerate the locomotive speed by half for the
purpose of shunting
0 – 12 0
156 Delay deactivation Nnumber of the function key which deactivates
the delays which are stored in CV3 and CV4
0 – 12 0
65 Software-Version Sub-number of the number of the software versi-
on of the decoder as displayed in CV7
Bit Function Value
0 Normal direction of travel
Direction reversal
0
1
1 14 driving stages in DCC system
28 / 128 driving stages in DCC system
0
2
2 Deactivate analogue operation
Activate analogue operation
0
4
3
RailCom
1)
off
RailCom
1)
on
0
8
4 3-point characteristic line in
accordance with CV2, CV5, CV6
28-point characteristic line in
accordance with CV67 -CV94
0
16
5 Use short address (CV1) in DCC
operation
Long address (CV17+18) in DCC
operation
0
32
Bit Function Value
0 Broadcast off
Broadcast on
0
1
1 Transmitting the CV data off
Transmitting the CV data on
0
2
