CV Name Description Value
Range
Works
Value
60 Dimming The performance of the function outputs can be
restricted (dimmed) by rapidly switching them on
and off. The function outputs are dimmed simul-
taneously
0 – 255 0
No
dimming
114 Dimming exception stipulate the function outputs which are not to
be dimmed in accordance with CV60
0 – 255 0
152 Dimming exception stipulate the function outputs which are not to
be dimmed in accordance with CV60
0 – 255 0
Bit Function Value
0 Front headlight dimmed
Front headlight not dimmed
0
1
1 Rear light dimmed
Rear light not dimmed
0
2
2 AUX1 dimmed
AUX1 not dimmed
0
4
3 AUX2 dimmed
AUX2 not dimmed
0
8
4 AUX3 dimmed
AUX3 not dimmed
0
16
5 AUX4 dimmed
AUX4 not dimmed
0
32
6 AUX5 dimmed
AUX5 not dimmed
0
64
7 AUX6 dimmed
AUX6 not dimmed
0
128
Caution!
Only the headlight
and the function out-
puts AUX1 and AUX2
can be dimmed when
using the decoders
10882 and 10884.
Caution!
Only valid for
the 10883
Bit Function Value
0 AUX7 dimmed
AUX7 not dimmed
0
1
Braking distance
The decoder is able to automatically brake the locomotive in brake sections which are not digital, but
which are either supplied with a direct current or with an alternating current (Märklin brake section). The
decoder is to be adjusted with CV programming before a reaction to these sections is possible.
First of all, the normal analogue operation has to be deactivated in CV29, i.e. Bit 2 is set at zero (0) or the
value 4 is deducted from the total value of the CV (the works value was 14).
The braking distances detection (direct current) also needs to be activated in CV124 Bit 5=1 (value 32). If
the Märklin braking distance with alternating current should be used, this is to be additionally activated
using CV112 Bit 6=1 (value 64).
