roco 10882 - Technical Data

15
GB
Note: You will nd additional functions for this decoder at www.zimo.at
Technical Data
Addresses: 1– 9999 (long DCC address)
Max. engine current / total load: 1 A
Function outputs (each and in total): 0,8A each
Dimensions: 20,0 x 11,0 x 3,5 mm (10882 and 10884)
22,0 x 15,0 x 3,5 mm (10883)
The decoder is preset at Address 03 with operating in 28 driving stages and can be driven and programmed
in DCC and Motorola
3)
data format.
Decoder protection:
▸ Temperature protection the decoder deactivates and the lights ash rapidly at 100°C.
▸ Short circuit monitoring of the motor and function connections.
1) RailCom is a registered trademark of the company Lenz GmbH, Giessen
2) Märklin is a registered trademark of the company Gebr. Märklin & Cie. GmbH, Göppingen, Germany
3) Motorola is a registered trademark of the company Motorola lnc.,Tempe-Phoenix/Arizona (USA)
1. Press the STOP and GO buttons at the same time until a reset is carried out
2. STOP button until deactivation of the track voltage
3. Enter address 80
4. Press the direction of travel switch and keep it pressed in and then additionally press GO for at
least 0.5 sec in order to reactivate the track voltage
5.
The decoder is in programming mode = slow ashing
6. Enter the register which is to be changed (two gures in the address eld)
7.
Conrm by pressing the direction of travel switch = rapid ashing
8. Enter the required value (two gures in the address eld)
9.
Conrm by pressing the direction of travel switch = slow ashing
Programming instructions for the Märklin
2)
6020/6021
A Märklin
2)
centre can be used to program all of the CVs but they cannot be read out.
▸ The controller has to be set to “0“.
▸ No locomotives are to be on the tracks except the one which is to be programmed!
▸ Please observe the locomotive lighting ashing signals during programming.
▸ Any number of changes/settings can be made as long as the decoder is in programming mode.
