roco Z21 switch DECODER User Manual

The Z21 is a FLEISCHMANN and ROCO innovation.
35
English
The switch decoder is then in “Conguration mode, option 1”.
2. Keep the programming button held down for at least 3 seconds again until the blue “Status” LED and white “Program” LED
begin to ash together. Then release the programming button again.
The white “Program” LED will then ash normally twice (short, short, pause; short, short, pause; etc.), and the red LED will be lit
continuously.
The switch decoder is then in “Conguration mode, option 2”.
3. Keep the programming button held down for at least 3 seconds again until the blue “Status” LED and white “Program” LED
begin to ash together. Then release the programming button again.
The white “Program” LED will then ash normally three times (short, short, short, pause; short, short, short, pause; etc.).
The switch decoder is then in “Conguration mode, option 3”.
4. The current addressing mode is displayed by the red LED for “ROCO” or the green LED for “RCN-213”.
The mode can now be switched over by briey pressing the programming button.
5. After you have selected the desired addressing mode, hold down the programming button for at least 3 seconds until the blue
“Status” LED and white “Program” LED begin to ash together. Then release the programming button.
The new setting is then applied and conguration mode is exited. The white LED goes out and the blue LED indicates normal
mode.
Factory setting: “ROCO”.
INFORMATION: Use the “RCN-213” setting for operation on control centres from other manufacturers, see also section Ope-
ration on control centres from other manufacturers .
6.2 Conguration via POM
The Z21 switch DECODER can be congured for your applications on the main track via POMprogramming commands and CVs. “POM”
stands for “programming on the main” and “CV” stands for “conguration variable”, which are described in detail in the section CV
list. No programming track is required.
If the DCC control centre and the Z21 control centres have a RailCom
®
receiver, these CVs can not only be written to, but also read.
When using the Z21 Single or Dual BOOSTER (10806, 10807) and the CAN-Bus, POM reading is also possible in the booster section.
INFORMATION: Before POM programming with control centres from other manufacturers, set the turnout addressing of the
Z21 switch DECODER to “RCN-213”! To set the turnout addressing, see section Option 3 – Set addressing mode.
When programming on the main track, a distinction must be made between POM programming commands for accessory decoders and
for loco decoders.
6.2.1 Conguration via POM programming commands for accessory decoders
When using POM programming commands for accessory decoders, the Z21 switch DECODER can be congured using the Z21-Mainte-
nance Tool at any time even when installed.
