SPECIFICATIONS
Acoustic Principle: Externally polarized 25 mm (1") condenser
Active Electronics: Valve impedance converter with bipolar output buffer.
Pickup Pattern: Multi pattern (see graph)
Frequency Response: 20 Hz ~ 20 kHz (see graph)
Output Impedance: 200
Sensitivity: -36 dB re 1Volt/Pascal (16 mV @ 94dB SPL) +/- 2dB
Equivalent Noise: 10 dB-A SPL (per IEC651, IEC268-15)
Maximum Output: > +30 dBu (@ 1% THD into 1k )
Dynamic Range: 150 dB (per IEC651, IEC268-15)
Maximum SPL: 162 dB (@ 1% THD into 1k )
Signal/Noise: > 81 dB (1kHz relative to 1 Pa; per IEC651, IEC268-15)
Power Requirements: Dedicated Power Supply (110 ~ 120V/220 ~ 240V, 50/60Hz)
Frequency Responses
