TABLE OF CONTENTS
- Specifications - 2 -
- Safety instructions - 3 -
- Installation of the mixing panel - 3 -
- Frontpanel, switches and control - 3 -
- Connections - 5 -
- Operating instructions - 6 -
- Subsonic filter - 7 -
- Pictures on cover - 27 -
SPECIFICATIONS
Inputs Input sensitivity Signal/Noise Ratio Remarks
PHONO 1-4
MD/AUX 1-4
CD/DAT 1-4
MIC 1-4 symm.
MIC DJ symm.
assym.
5.2mV/50kΩ
500mV/50kΩ
500mV/50kΩ
9.1mV/4kΩ
3.6mV/1.2kΩ
3.2mV/22kΩ
< -80dB
< -92dB
< -92dB
< -83dB
< -85dB
< -89dB
RIAA correction
Outputs
Master symm. 1-2
Master assymm. 1-2
Monitor assym.
Effects insert DJ-mic
Effects insert music
Recording 1-4
Phones
1.55V/600Ω
775mV/10kΩ
775mV/10kΩ
775mV/10kΩ
775mV/10kΩ
500mV/10kΩ
12V/600Ω
Subsonic filter
Subsonic filter
Subsonic filter
Recording out selector
Phones 200-600Ω
- Tone controls: Bass +/-13dB @ 100Hz
Middle +/-13dB @ 1kHz
High +/-13dB @ 10kHz
- Subsonic filter: -25dB @ 10Hz
- Power source: Panels are leaving the factory on: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
- Fuse: T500mA
- Power consumption: OFF=2.0VA ON=38.2VA
- Approbation: CE-approved
- Dimensions: Front: 482mm x 310mm (19” x 7HE)
Chassis: 444mm x 295mm x 150mm
- Weight: 6.3kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL MX180 50th anniversary edition
SERIAL NUMBER …………………………… (on the back of the set)
Please give model and serial number by when you request info.
Thank you very much for purchasing the RODEC mixing panel MX180 50th anniversary edition.
This mixing panel is a topline-mixing panel, capable of outstanding performance in combination with
high-grade systems.
