11) On the right VU-meter the signal appears selected with the VU2-signal select switch (4). If you
like to compare via the headphones and the left VU-meters the pre-fade signal with the output
signal, you can do this by putting the rotative switch (4) on the SUM-position. By this the PFL-
signal appears on the two left VU-meters and the output-signal on the other two VU-meters.
12) If the DJ likes to connect monitor-loudspeakers, he can use the monitor-output (K) for this.
This output is free of the DJ-microphone signal, to avoid feedback from the speakers to the
microphone.
SUBSONIC FILTER
The two master outputs and the monitoroutput have a subsonic filter to protect the bass loudspeakers
from DC and subsonic signals. This filter cannot be switched off. The filter gives a reduction of 25dB at
10Hz.
