M) Second headphones connector
Signal identical as headphones-output on the frontpanel (6) when connection on the
frontpanel is not in use. The specifications are the same as the headphones output on the
frontpanel.
N) Primary fuse
Primary fuseholder, please use only the same type of fuse as indicated on the backpanel.
O) Power inlet
Mains power inlet, please connect only to the same mains voltage as indicated on the
backpanel.
Please use signal cables shorter than 1 meter for the inputs and the outputs.
OPERATING INSTRUCTIONS
1) First switch all the connected music-sources on (like CD-players, recordplayers, etc.). Then
switch the power button (1) to turn the power supply on. The power indicators (2) will light up
and a few seconds later the mixing panel will be in operation, ready state. In this stage you
can turn on the power amplifiers.
2) Connect the headphones to phones output (6) or (M).
3) Choose with input switch (10) the right source.
4) Switch the PFL button (9) in position ON to listen at the desired source. Turn the phones
select button (6) completely to the left and turn the phones volume potentiometer (5) up to the
desired position, to get the stereo signal on the headphones and the two left VU-meters. The
PFL circuit works as a sum-system, there is possibility to listen to more sources at the same
time. Al these operations have no influence on the outputsignal! Adjust with the level control
(11) the input signal, so that the red indicators of the level meters (3) light up sometimes.
Adjust if necessary the quality of the sound with the equalizer (12).
LOOK OUT:
- The equalizer at each input is used to adjust the different sound
between the sources. To correct the acoustic of the room it is probably best to
use an external equalizer.
5) Slide up the fader (14) of the choosen source.
6) Adjust with the master (21) the volume.
7) Correct if necessary the panorama/balance with button (13), for monophonic sound set switch
(5) in mono position.
8) To change the source, repeat point 3) to 5).
9) To add a microphone signal, connect the mike to the MIC input (15) or (G) input. Please
connect only one microphone, input 16 or input G. Turn the level control (16) and the talk-over
(19) to zero, slide up the MIC fader (20) to maximum and adjust with the level button (16) the
volume of the microphone. Adjust with the equalizer (17) the sound of the mike. To use the
talk over, adjust the talk over button (19) (0= no decrease, 10= total decrease). With the pan
MIC (18), the DJ microphone signal can be placed somewhere between left and right.
10) If you like to record the mixed signal, you can simply do this by connecting a recorder to the
record-connectors (F). Depending on the position of the record-select switch (23) you can
decide if the microphone signal is also recorded or not.
