22
1. INPUTS - OUTPUTS - CONTROLS
A
B
Amplifier internal ventilation
A = air inlets (top)
B = air outlets (bottom)
FRONT PANEL
R2100A2
R2180A2
REAR PANEL
R2100A2
R2180A2
