30
R4100A2 R2180A2 R2100A2 R1500A2
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<0.1%) 4x85W 2x185W 2x105W 1x355W
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<1%) 4x95W 2x190W 2x110W 1x375W
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 2 Ohms (THD<1%) 4x140W 2x310W 2x150W 1x555W
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<1%) Bridged 2x280W 1x610W 1x300W n.a.
Damping Factor @ 4 Ohms Load All Channels > 200 > 200 > 200 > 200
Signal-to-Noise Ratio (A-Filter Weighted)
All Channels @ full rated power output > 95dB > 95dB > 95dB > 95dB
Frequency Response (-3dB)
Operation Mode set to FULL,
All Channels driven simultaneously 10Hz - 40kHz 10Hz - 40kHz 10Hz - 40kHz 10Hz - 40kHz
Channel Separation
All Channels > 55dB > 55dB > 55dB > 55dB
Input Sensitivity
All channel Pairs 0.2V - 9V 0.2V - 9V 0.2V - 9V 0.2V - 9V
Integrated Cross-Over/Filtering
Slope Rates 12 dB/Octave High- & Lowpass
Highpass Cross-Over Frequency Range continuously variable 10 - 400 Hz
Lowpass Cross-Over Frequency Range continuously variable 30 - 400 Hz
Fuses 3x25 A 3x25A 2x20A 2x30A
Dimensions (W x H x D) 384 x 59 x 270 mm 405 x 59 x 270 mm 292 x 59 x 270 mm 384 x 59 x 270 mm
5. TECHNICAL SPECIFICATIONS
