User Manual P11
Installation:
05
Hanging System
0.5m Hanging bar Dimensions:
1m Hanging bar Dimensions:
Hanging bar components:
494mm
994mm
158mm
158mm
205mm 205mm
Hanging ClampsAdjusting Knob
Adjusting Screw
Vertical Assitant Position Bead Magnet
Hanging Installation
1. Fix the Hanging Bar on the Truss
Just turn the Adjusting Screw, to make the Clamps close, the Hanging Bar will be
fixed on the Truss safely.
To Next Page
