ROE BP2 User Manual

03
Connection
User Manual P7
Evision
AC 220V
USB
DVI
①
②
Evision
AC 220V
USB
DVI
①
②
BP Built in Power Supply
Input Voltage AC 220V
Hanging System
BP Built in Power Supply
Input Voltage AC 110V
1. Neither Header nor Connector can load more than 20 tiles of BP.
2. When the Input Voltage is 220V, one Power Cable can load 16 tiles of BP; and the Input Voltage is 110V, one
Power Cable can load 8 tiles of BP.
Notes:
AC 220V AC 220V AC 220V AC 220V AC 220V AC 220V
③
④
⑤
⑦
⑥
⑤ ⑥
⑧
⑦ ⑧
AC 220V AC 220V AC 220V AC 220V AC 220V AC 220V
③
④
16 tiles high 8 tiles high
BP BP BP BP BP BP
BP BP BP BP BP BP
BP BP BP BP BP BP
BP BP BP BP BP BP
BP BP BP BP BP BP
BP BP BP BP BP BP
BP BP BP BP BP BP
