HOOKUP INSTALLATION & PROGRAMMING BOOK
4
 Message duration and dialing attempts' number are programmable;
 Monitoring system state, battery state and AC power;
 EEPROM memory retains the programmed configuration even after all
power was removed from the control panel;
 Up to 4 keypads, 4 wire linked;
 Keypad tamper using microswitch;
 Individual state LEDs for each zone, indicating the alarm state;
 System state LEDs (READY, SYSTEM, ARMED).
TECHNICAL SPECIFICATIONS:
Power
 12V/4Ah battery;
 50mA stand-by current;
 typical 500mA power output on AUX power supply source
Inputs
 4 fully programmable 2K2 EOL zones on board;
 1 Keyswitch/tamper 2K2 EOL zones on board.
Outputs
2 "open-collector" outputs with negative trigger (NPN), max. 50mA;
• 1 "open-collector" siren output with positive trigger (PNP), typically 1A.
