The direcon and the height of the handlebar is adjusted by fastening and
unfastening the screw on the outside of the joint, between the handlebar and
the stem. Use a no. 6 hex key to unfasten the screw by rotang it an-clockwise.
Adjust the handlebar to the desired height and direct it perpendicularly to the
front wheel. When you adjust the height and the direcon, fasten the
handlebar by fastening the screw clockwise (torque 18 Nm).
The height of your seat is adjusted using a quick release lever posioned on the
joint between the seat post and the frame. In order to adjust the seat height,
unfasten the fastener lever and adjust the seat to the desired height. Once you
decide on the height, direct the seat towards the front and fasten the lever, so
that it fully clasps the bike frame.
In order to adjust the inclinaon and the posion of the seat, use a no. 6 hex
key. Unscrew the screw under the seat an-clockwise and adjust the seat to the
desired posion. Then, fasten the screw clockwise with a torque of 8 Nm.
The simple folding or disassembly of the bike frame is enabled by a quick
release system. Unfasten the quick release lever and fold the bike frame in half
on the right side. When assembling the bike to its operang posion, it is
important that the joint fits together suitably before you fasten the quick
release lever.
In order to adjust the handlebar inclinaon, use a no. 6 hex key. Place the key
on the screw that is fastened on the inside of the joint between the handlebar
and the stem. Rotate the key an-clockwise to unfasten the joint and change
the inclinaon of the handlebar. Once the handlebar is placed in the desired
posion, rotate the key clockwise and fasten the handlebar (torque 18 Nm).
In order to fasten and unfasten any key parts of your Pony bike, you
can use a no. 6 HEX key (this tool is enclosed with your purchased
bike) and by manually operating the quick release system.
1
1
2
2
3
3
5
4
4
5
ROG Bikes Manual for the Use of the Pony Folding Bike Page 14
