1. Switch the controller unit on. LED L1 turns on, LED L3 turns on (if the photocells are not obscured and are
correctly aligned).
2. Interrupt the light beam between the photocells with a 50 mm diameter cylindrical object. The automac
door or gate must stop or reverse direcon. The red LED L3 exnguishes.
3. Repeat the procedure, stand near the TX photocell and interrupt the light beam.
4. Repeat the procedure, stand near the RX photocell and interrupt the light beam.
5. When installing two or more pairs of photocells, repeat the same procedure, taking care to check for any
interference between them.
10 Maintenance
Perform scheduled maintenance every 6 months.
Check that the photocells are clean and are working correctly. In parcular, keep the outer surfaces of the RX
receiver and the TX transmier clean.
If any dirt, moisture, insects or other obstrucons are found, clean the photocell and repeat the inial tesng
procedure.
If any corrosion is found on the printed circuit board, evaluate if it is necessary to replace the board itself.
11 Disposal
This product may only be uninstalled by qualied technical personnel, following suitable procedures for
removing the product correctly and safely. This product consists of numerous dierent materials.
Some of these materials may be recycled, while others must be disposed of correctly at the specic
recycling or waste management facilies indicated by local legislaon applicable for this category of
product. Do not dispose of this product as domesc refuse. Observe local legislaon for dierenated
refuse collecon, or hand the product over to the vendor when purchasing an equivalent new product.
Local legislaon may envisage severe nes for the incorrect disposal of this product. Warning! some parts of this
product may contain substances that are harmful to the environment or dangerous and which may cause
damage to the environment or health risks if disposed of incorrectly.
12
I the undersigned, as acng legal representave of the manufacturer:
Roger Technology
hereby DECLARE that the appliance described hereaer:
Descripon: Photocell for automac doors and gates
Model: M90
Is conformant with the legal requisites of the following direcves:
• 2014/30/CEE
• 2014/35/EU
• 2011/65/EU
and that all the standards and/or technical requirements indicated as follows have been applied:
EN 61000-6-3; EN 61000-6-2
Last two gures of year in which marking was applied | 17.
Place: Mogliano V.to
Date: 10-05-2017 Signature
