which indicates sector where PCN number is
stored (by default Roger AID number is: 5156).
Block ID
0..15
Specifies block number within sector where PCN
code is stored.
Key type
0 - A
1- B
2- Roger
Specifies key type used to encrypt data stored on
the card.
Key
000000000000 –
FFFFFFFFFFFF
6 bytes key used to encrypt data stored on the
card.
Programmable card number (PCN) settings for Mifare Plus
Sector type
0 – NONE
1 – SSN
2 – MAD
Specifies the type of sector where PCN number is
stored. If value ‘0’ is chosen then RCN will be
formed from CSN number only.
Format
0 – HEX
1 – HEX ASCII
Specifies coding method of PCN number in data
block.
First byte position
(FBP)
0..15
Specifies position of the byte in data block where
PCN number begins.
Last byte position
(LBP)
0..15
Specifies position of the byte in data block where
PCN number ends.
Sector ID
0..39
Data sector where PCN number is stored.
Application ID (AID)
0000..FFFFF
Specifies AID number (Application Identifier)
which indicates sector where PCN number is
stored (by default Roger AID number is: 5156).
Block ID
0..15
Specifies block number within sector where PCN
code is stored.
Key type
0 - A
1 - B
Specifies key type used to encrypt data stored on
the card.
Key
00000000000000000
000000000000000..F
FFFFFFFFFFFFFFFFFF
FFFFFFFFFFFF
16 bytes key used to encrypt data stored on the
card.
Programmable card number (PCN) settings for Mifare DESFire
Sector type
0 – NONE
1 – DESFire file
Specifies the type of sector where PCN number is
stored. If value ‘0’ is set then RCN will be formed
from CSN number only. If value ‘1’ is chosen then
PCN code will be read form file on the card.
Format
0 – HEX
1 – HEX ASCII
Specifies coding method of PCN number in data
block.
First byte position
(FBP)
0..15
Specifies position of the byte in data block where
PCN number begins.
Last byte position
(LBP)
0..15
Specifies position of the byte in data block where
PCN number ends.
Application ID (AID)
0000..FFFFF
Specifies AID number (Application Identifier)of
the file where RCN code is stored. Mifare DESFire
can hold up to 28 AID numbers.
