Roger PRT12MF-DES - 2 Operating Modes and Output Formats

PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc
2018-08-23
6/23
CSN
C1h
C2h
C3h
C4h
C5h
C6h
C7h
Section PCN=223344
PCN
Poz.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
BIN
AAh
BBh
CCh
DDh
EEh
FFh
00h
11h
22h
33h
44h
55h
66h
77h
88h
99h
then RCN is RCN=CSN+PCN=C4C5C6C7223344.
RCN
CSN section
PCN section
C4h
C5h
C6h
C7h
22h
33h
44h
The number returned by PRT reader with Wiegand 66 bit output format (64 data bits + 2 control
bits):
00
C4h
C5h
C6h
C7h
22h
33h
44h
The number returned by PRT reader with Wiegand 42 bit output format (40 data bits + 2 control
bits):
C6h
C7h
22h
33h
44h
The number returned by PRT reader with Wiegand 26 bit output format (24 data bits + 2 control
bits):
22h
33h
44h
The number returned by PRT reader in RACS CLK/DTA output format (40 data bits):
C6h
C7h
22h
33h
44h
Note:
1. The RCN returned by reader includes only CSN section if the parameter Sector type=None and
the parameter Serial number length (CSNL) is in range of 1-7 depending on the number of bytes
intended for identification.
2. The RCN returned by reader includes only PCN section if the parameter Sector Type≠None and
the parameter Serial number length (CSNL)=0 .
3. If the actual RCN is longer than the maximal length for particular output format then the reader
cuts leading bytes when transmitting the RCN to access controller. It concerns RACS CLK/DTA
format which always transmits 40 data bits and Wiegand formats which can transmit 2 to 8 bytes
(16..64 bits).
4. If the actual RCN is shorter than the maximal length for particular output format then the reader
inserts leading zeros when transmitting the RCN to access controller. It concerns RACS CLK/DTA
format which always transmits 40 data bits and Wiegand formats which can transmit 2 to 8 bytes
(16..64 bits).
2. OPERATING MODES AND OUTPUT FORMATS
Readers can be configured with RACS CLK/DTA or Wiegand 26..66 bit operating modes.
Additionally, output formats can be configured for Wiegand mode.
