Security Locks SL2000E v1.2 EN Rev.A.doc 2011-09-01
Page 5 of 11
[#] - Exit from the Installer Programming mode
When the code lock accepts the new USER code it generates two series of two beeps (** **). Any attempt to
program a USER code which already exists in memory or to program it with a code length bigger then
programmed during Memory Reset will cause the programming error signalled by the long acoustic beep.
Configuring the SL2000 ( Memory Reset)
In order to configure the SL2000 you must perform the Memory Reset and then enter sequentially 10 digits
(called C1-C10) which will configure the unit for individual installation. After the Memory Reset the entire
contents of the code lock memory is erased (including all codes) and initialized with Default (Factory) settings.
These values
In order to perform Memory Reset do the following steps:
· Turn off the power supply
· Connect Reset wire (Brown-Yellow) to supply plus
· Turn on the power supply
· Wait till the moment when device will sound three series of two beeps (** ** **) - this signal indicates that
SL2000 erased memory and restored default configuration settings
· Disconnect Reset wire (Brown-Yellow) from supply plus
· Enter sequentially ten digits C1-C10
· After the last digit is entered the code lock generates the three series of two beeps (** ** **) then ends
the Memory Reset procedure and switches to normal working mode.
Meaning of the configuration parameters: C1-C10
C1C2: Open Delay, specifies the time delay from a moment when access is granted to a moment when Door
Relay will be activated. It can be programmed from 00 to 99s (default: 04).
C3C4: Lock Activation Time, specifies the time for which Door Relay will be activated when access is granted.
It can be programmed from 00 to 99s (default: 04).
C5C6: Time for Door Closing, specifies the time within which door must be closed. It can be programmed from
00 to 99s, the 00 value sets unlimited time for closing (default: 09).
C7: Enables or disables of reprogramming of the MASTER and INSTALLER codes, enter 0-3 (default: 0).
Value Reprogramming of the MASTER code Reprogramming of the INSTALLER code
0 Enabled Enabled
1 Disabled Enabled
2 Enabled Disabled
3 Disabled Disabled
C8: Enabling and disabling Option 1 and Option 2, enter 0-3 (default:0).
Value Option 1 Option 2
0 Disabled Disabled
1 Enabled Disabled
2 Disabled Enabled
3 Enabled Enabled
Option 1: Timed Lock-out
Note: If reprogramming of a given code is disabled the SL2000 allows you a single attempt only to program of
the given code. Once the code is programmed, you will not be able to change it unless the Memory Reset is
carried out. Use this function to disable the end user to change your MASTER and INSTALLER code
