Usage: Query only
BUS<b>:UART:FRAMe<n>:WORD<o>:STOP?
BUS<b>:UART:RX:FRAMe<n>:WORD<o>:STOP?
BUS<b>:UART:TX:FRAMe<n>:WORD<o>:STOP?
Returns the end time of the specified symbol (word).
Suffix:
<b>
.
1..4
<n> *
Selects the frame.
<o> *
Selects the word number.
Return values:
<StopTime> Range: depends on sample rate, record length, and time
base
Increment: depends on the time base
Default unit: s
Usage: Query only
BUS<b>:UART:FRAMe<n>:WORD<o>:VALue?
BUS<b>:UART:FRAMe<n>:WORD<o>:RXValue?
BUS<b>:UART:FRAMe<n>:WORD<o>:TXValue?
BUS<b>:UART:RX:FRAMe<n>:WORD<o>:VALue?
BUS<b>:UART:TX:FRAMe<n>:WORD<o>:VALue?
Return the value of the specified symbol (word) on the Rx line and Tx line, respectively.
Suffix:
<b>
.
1..4
<n> *
Selects the frame.
<o> *
Selects the word number.
Return values:
<Value> Range: 0 to 511
Increment: 1
Usage: Query only
17.11.5 CAN (option R&S RTM-K3)
CAN is the Controller Area Network, a bus system used within automotive network
architecture.
Serial bus analysis
