Fig.1 - Panel Controls for the DFC-10P
Fig.2 - Panel Controls for the DFC-50P
1. Ammeter - displays current / load
2. 15 Amp fuse
3. 6 / 12 Volt switch
4. 3 Amp fuse
5. Amp output switch, MIN - Trickle charge / MAX - Fast Charge
1. Ammeter - displays current / load
2. Mode switch - charging / jump start
3. 12 / 24 Volt switch
4. 10 Amp fuse
5. Amp output switch, MIN - Trickle charge / MAX - Fast Charge
