Roidmi RS70 - Assembly

EN
5
Wall-mounted charging dock
(with auxiliary parts)
Power adapter
(cord length: 1.5 m)
Cleaning brush LX02 HEPA filter
6. Assembly
a) Assembling your vacuum cleaner
b) Assembling accessories
There are a variety of accessories that are compatible with this vacuum cleaner. Attach desired accessory or cleaning tool to the vacuum cleaner for specific cleaning
purpose.
Attaching crevice tool: Insert release button end of the crevice tool into the main unit. Push it in until it clicks securely into place.
Accessories which can be directly connected to the main unit include mattress brush. The method for attaching them is the same as for attaching the crevice tool.
c) Installing wall-mounted charging dock
Wall-mounted charging dock is designed to store and charge the vacuum cleaner while not in use. Be sure it is installed near an outlet.
Method 1: Installing with screws
Make sure there are no gas, water or electrical pipes/wires behind the mounting area before drilling.
1. Remove small plastic caps on the charging dock. At a height of 92 cm, position
the charging dock on the wall and mark the fixing hole positions. Make sure
fixing holes are on a horizontal line.
2. Drill fixing holes and hammer wall plugs into the holes.
92 cm
3. With the charging contacts on the top, put the charging dock in place and fix
it with screws.
4. Put the caps back to cover the holes.
Method 2: Installing without screws
This installation method is not applicable to peeling walls, dirty walls and walls of poor quality. Ensure the wall is clean and free of dust before installing.
1. Measure a height of 92 cm and mark the installation
position.
2. Remove the protective film. 3. With the charging contacts on the top, paste the
charging dock on the wall, pressing slightly to make
sure it is firmly adhered to the wall.
92 cm
