• Remove the stencil and make the holes in the wall.
• Fix the supports using the plugs and screws provided or others
suitable for the wall type.
• Check the correct positioning of the lower support.
• Align the radiator with the top supports.
• Place the radiator on the supports.
Installing template measurements depending on the model:
SRN0440RAD2
Floor
210 mm
642 mm
161 mm
81 mm
161 mm
322 mm
642 mm
210 mm
Floor
SRN0660RAD2
