- 45 -
PARTS LIST FOR FC2002
Schematic # Description Part # Qty.
1 2 HP Pump/Motor PMP11MK246FC 1
2 Drain Valve (thumb screw style) FC022029000 2
Drain Valve (ball-valve style starting 8/13) FC9047062 2
3 Tank Assembly FC162QC0010 1
4 Handle Grip FC127GH0012 1
5 Gauge – Line FC330006001 1
6 Regulator FC319205000 1
7 Nipple FC011017000 1
8 Gauge – Tank FC330063001 1
9 Safety Relief Valve FC047027000 1
10 Bleeder Valve FC011158000 1
11 Discharge Tee FC199617000 1
12 Ring FC011117000 1
13 Lock Nut FC011117002 1
14 Discharge Tube
(includes FC011117000 & FC011117002)
FC2002-DISCH TB 1
15 Lock Nut FC199437000 1
16 O-Ring FC010024000 1
17 Spring 047113002F 1
18 Disc 047113001F 1
19 Check Valve FC347043000 1
20 Nut FC014003002 3
21 Washer FC014008008 3
22 Brass Sleeve FC011304000 1
23 Nylon Tubing – 9” FC046001000 .75
Ring 011077000F 1
24 Bolt FC014001041 4
25 Screw FC014013042 4
26 Washer FC014005002 8
27 Rubber Foot FC020004001 4
28 Nut FC014003001 4
29 Cord with Plug FC164A08300 1
30 Pressure Switch FC321054000 1
31 Nipple FC011017001 1
32 Vibration Dampener FC199575000 4
33 Mounting Plate FC127GH0010V75 1
606 South Lake Street > P.O. Box 346 > Hustisford, WI 53034-0346 > 920.349.3281 > fax 920.349.3691 > www.rolair.com
