Rolair FC2002 - Page 47

- 47 -
PARTS LIST FOR PMP11MK246FC
Schematic # Description Part # Qty.
1 Bolt FC014002021 4
2 Head FC116022002 1
3 Intake Filter Assy. (Mdl’s FC2002, FC2002HBP6) FC317007000 1
(Mdl’s D2002HPV5, D2002HSSV5 )
317013000F 1
4 Gasket FC116022007 1
5 Valve Plate FC116022013 2
6 Gasket FC116022014 1
7 Valve FC116022038 2
8 Gasket FC116022012 1
9 Cylinder FC116093009 1
10 Bolt FC014011064 2
11 Gasket FC116091016 1
12 Ring Set FC216022002 1
13 Piston FC116022004 1
14 Piston Pin FC116022040 1
15 Snap Ring FC015001000 2
16 Piston Assembly FC416022004 1
17 Connecting Rod FC116091021 1
18 Capacitor FC009200075 1
19 Capacitor Cover FC116034013 1
20 Dipstick FC312043000 1
21 Screw FC014013021 4
22 Crankcase Cover FC116091002 1
23 O-Ring FC010072000 1
24 Drain Plug FC014013024 1
25 Diaphragm FC116091011 1
26 Motor Housing FC116091001 1
27 Nut FC014003002 2
28 Washer FC014005009 2
29 Manual Reset Button FC008331000 1
30 Crankshaft FC116022011 1
31 Bearing FC033027000 1
32 Seal FC010029000 1
33 Rotor FC116092003 1
34 Stator FC416QC4652 1
35 Bearing FC033005000 1
36 End Bell FC116011002 1
37 Bolt FC116011038 2
38 Fan FC116001003 1
39 Shroud FC116QC0001 1
40 Screw FC014006121 2
41 Gasket Set FC216093003 1
606 South Lake Street > P.O. Box 346 > Hustisford, WI 53034-0346 > 920.349.3281 > fax 920.349.3691 > www.rolair.com
