- 45 -
PARTS LIST FOR MODELS
GD4000PV5H
GD4500PV5R
Schematic # Description Part # Qty.
1 Pump - Less Engine PMP11MK238FI 1
Honda Engine – GD4000PV5H ENG04H01 1
Robin Engine – GD4500PV5R ENG04R01 1
2 Pilot Unloader Valve 131B 1
3 Nipple BLNP0250X0875 1
4 Tee BLTE0250 1
5 Safety Valve SRV0250N165 1
6 Brass Elbow BREL0500X037539 2
7 Discharge Tube GD4000PV5H-DISCH TB 1
8 Gauge GA0125200 2
9 Regulator REG0250M 1
10 Quick Disconnect 308 1
11 Coupler Plug 310 1
12 Check Valve CV3X4T 1
13 Brass Straight BRST0250X012538 1
14 1/4” Nylon Tubing – 16” 178D 1.25’
Brass Ring BRRG0250 2
Brass Nut BRNT0250 2
Brass Sleeve BRSL0250 2
15 Screw MIS10093C 6
16 Rubber Foot 219B 6
17 Drain Valve 132B 1
18 Brass Coupler BRCP0250X0250H12 1
19 Hose Clamp 177 2
20 1/4” Rubber Hose – 18” 178 1.5’
21 Brass Coupler BREL0250X0250H16 1
22 Tank Assembly TNKASYGDPV5 1
23 Accessory Bracket 212 1
24 Throttle Control Kit – Honda 192EGX120K1QX 1
Robin 192EEX130D50020 1
25 Hose Clamp 177 2
26 1/4” Rubber Hose – 18” 178 1.5’
606 South Lake Street > P.O. Box 346 > Hustisford, WI 53034-0346 > 920.349.3281 > fax 920.349.3691 > www.rolair.com
